Robust waterproof immersion/penetration probe (Pt100)

Robust Waterproof Immersion/Penetration Probe (Pt100)

Engineered for precision laboratory and industrial applications, this robust waterproof immersion and penetration probe utilizes a high-accuracy Pt100 sensor. It is specifically designed to deliver exceptionally reliable temperature measurements in liquid and semi-solid media.

The waterproof construction makes it highly practical for demanding environments where exposure to moisture is constant. With an optimized tapered tip, the probe balances durability with a minimized thermal mass to ensure rapid thermal equilibrium without sacrificing structural integrity.

Tradie Pro Tip: To achieve that precise 12-second reaction time, make sure the entire 50 mm stepped tip is fully submerged! The Pt100 element needs maximum surface contact to continuously deliver its true Class A performance.

Key Technical Highlights

• High-accuracy Pt100 sensor ideal for stringent laboratory and quality assurance requirements
• Fully waterproof construction for demanding measurement environments
• Broad measuring range from -50 to +400 °C
• Rapid 12-second reaction time in liquid media

---

Technical Specifications

Temperature - Pt100

Feature	Value
Measuring range	-50 to +400 °C
Accuracy	Class A (-50 to +300 °C) Class B (Remaining Range) ¹
Reaction time	12 s

¹ According to standard 60751, the accuracies of Class A and B refer to -200 to +600 °C (Pt100).

Physical Dimensions & General Data

Feature	Value
Length probe shaft	114 mm
Length probe shaft tip	50 mm
Diameter probe shaft	5 mm
Diameter probe shaft tip	3.7 mm
Cable length	1.2 m
Fixed cable	yes

---

Delivery Scope

1 x Robust waterproof immersion/penetration probe (Pt100) with a 1.2 m fixed cable (Product no. 0609 1273).
