Seeley Magiq Touch Control Box (Post 2016 Dual Port)

This Seeley Magiq Touch Control Box (SY116815) is your go-to replacement for specific post-2016 Seeley evaporative cooler models. It's a critical component for controlling your unit's operation and ensuring it runs as expected.

Designed to keep your cooler running smoothly, especially during those long Aussie summers when reliability is crucial. Nothing worse than a control fault on a 40-degree day when you need that evaporative cooling working.

Best For

• HVAC service technicians
• Evaporative cooler specialists
• Competent DIY owners maintaining Seeley Magiq Touch systems

Compatibility

This control box is designed specifically for Seeley Magiq Touch evaporative coolers manufactured Post 2016 with a dual port external sensor. It suits the following models: EXQ, EZQ, EXS, and RPCQI.

If you're running a different model, always check your existing control box and unit specifications before ordering to ensure correct fitment.

Features

• Genuine Seeley Part: Ensures direct fitment and reliable performance, matching original factory specifications.
• Magiq Touch System: Designed for seamless integration with Seeley's Magiq Touch control systems.
• Post 2016 Compatibility: Specifically for units manufactured after 2016, ensuring updated circuit design and componentry.
• Dual Port External Sensor: Features the necessary connections for dual port external sensor configurations.

What's in the Box

• 1 x Seeley Magiq Touch Control Box (Part/Code: SY116815)

Using It on the Job

1. Isolate Power: Always ensure the main power supply to the evaporative cooler is switched off at the breaker and locked out before commencing any work.
2. Access Control Box: Carefully open the cooler's access panel to locate the existing control box.
3. Document Connections: Take photos or make a diagram of all wiring connections before disconnecting anything. Pay close attention to the external sensor wiring.
4. Replace Box: Disconnect all wires and the sensor, remove the old control box, and mount the new SY116815 unit in its place.
5. Reconnect & Secure: Reconnect all wiring exactly as documented. Ensure the external sensor is properly attached and secured.
6. Test Functionality: Restore power and thoroughly test all functions of the evaporative cooler via the Magiq Touch wall controller to confirm correct operation.

Limitations & Safety Notes

• Always isolate the main power supply and follow lockout/tagout procedures before working on electrical components.
• This control box is only compatible with specific Seeley Magiq Touch evaporative coolers that are Post 2016 models and utilise a dual port external sensor.
• Installation should be performed by a qualified tradesperson or competent individual familiar with evaporative cooler electrical systems.
• Refer to the specific Seeley service manual for your cooler model for detailed installation instructions and wiring diagrams.

Tradie Pro Tip: Before you swap out the control box, double-check your wall controller settings and the wiring harness for any obvious faults. Sometimes it's a simpler fix than you think, especially if the old box was just struggling with an intermittent connection.

Pair With

Pair with other Seeley Wall Controllers or other genuine Seeley spare parts for your evaporative cooler to keep your system in top condition. Also consider checking your evaporative cooler filter pads for optimal performance.
