Imperial 560-FTY 150cm 500 Series Evacuation Hose 3/8"

Name: Imperial 560-FTY 150cm 500 Series Evacuation Hose 3/8"
Brand: Imperial
Price: 119.99 AUD
Availability: InStock

The Imperial 560-FTY is a 150cm large-bore evacuation hose from the Imperial 500 Series, designed to minimise flow restriction during deep vacuum pull-down. The 3/8" fitting connects directly to vacuum pump inlets, and the large internal bore allows air and moisture to be evacuated faster than standard charging hoses — reducing evacuation time on residential and commercial HVAC/R systems.

For standard 3/8" charging and vacuum hoses, see the Mastercool 94160. For manifold gauge hose sets, see the Mastercool 40360. See all refrigeration tools at HVAC Shop AU.

Key Features

Large-bore construction — minimises flow restriction during evacuation
3/8" fitting — standard vacuum pump inlet connection
150cm (5ft) hose length
500 Series — designed for fast deep vacuum pull-down
Not for refrigerant charging use

Specifications

Length	150cm (5ft)
Fitting size	3/8"
Series	Imperial 500 Series
Application	Evacuation only

What’s Included

Imperial 560-FTY evacuation hose (150cm)

Common Questions for Imperial 560-FTY 150cm 500 Series Evacuation Hose 3/8"

What makes the Imperial 500 Series evacuation hose different from a standard charging hose?

The 500 Series uses a large-bore internal diameter specifically designed to minimise flow restriction during evacuation. Standard charging hoses have a smaller internal bore suited to refrigerant flow, but this restricts vacuum pull-down speed. The 560-FTY is optimised for achieving deep vacuum faster.

What fitting size does the Imperial 560-FTY use?

The 560-FTY uses a 3/8" fitting — the standard connection size for vacuum pump inlets. It connects directly to the vacuum pump port and the system service port for evacuation without adapters.

Can I use the Imperial 560-FTY for refrigerant charging?

The 560-FTY is designed specifically for evacuation. For refrigerant charging through a manifold gauge set, use 1/4" or 5/16" SAE hose sets. Using an evacuation hose for charging is not recommended as the large bore is not suited to controlled refrigerant flow.
