Flexible Flue Gas Probe

This Testo flexible flue gas probe is your go-to when you're trying to get a reading from a burner in a really tight spot. Its bendable plastic shaft means you can snake it into measurement apertures that are otherwise impossible to reach, like behind sloping ceilings or in cramped plant rooms. Anyone who's wrestled a rigid probe into an old boiler knows the frustration this little beauty solves.

Best For

• Heating system technicians dealing with older or cramped installations.
• Service teams needing to access obstructed flue gas measurement points.
• Apprentices learning to navigate tricky burner setups.

Compatibility

This flexible flue gas probe connects to your flue gas analyser via a standard bayonet fitting. It’s designed to work seamlessly with various Testo flue gas analysers, including models like the Testo 300 Longlife and Testo 300 NEXT LEVEL kits. If you're running a different model, check fittings and specs before ordering.

Features

• Flexible Plastic Shaft: The probe shaft is made from durable, flexible plastic, allowing you to bend it without the risk of kinking or breaking, unlike metal probes.
• Access Difficult Spots: Specifically designed for measurements at obstructed or hard-to-reach flue gas apertures.
• Bayonet Fitting: Ensures a quick and secure connection to compatible Testo flue gas analysers.
• High Temperature Resistance: Rated for continuous use up to 180 °C, with short-term resistance up to 200 °C.
• Optimal Length: At 330 mm, the probe shaft offers good reach for most common installations.

Technical Specifications

What's in the Box

• 1 x Testo Flexible Flue Gas Probe (0600 9770)

Using It on the Job

1. Prepare Analyser: Ensure your Testo flue gas analyser is calibrated and ready for use.
2. Connect Probe: Attach the flexible flue gas probe to your analyser using the bayonet fitting. Make sure it clicks securely into place.
3. Access Measurement Point: Carefully bend the flexible shaft as needed to navigate obstructions and insert the probe into the flue gas aperture.
4. Perform Measurement: Follow your analyser's instructions to take accurate flue gas readings.
5. Remove & Clean: Once done, carefully withdraw the probe. Allow it to cool, then wipe down the shaft to remove any soot or debris before storing.

Limitations & Safety Notes

• Do not exceed the maximum continuous operating temperature of 180 °C (200 °C short-term) to prevent damage.
• Always ensure proper ventilation when working on heating systems and follow local safety guidelines.
• This probe is for flue gas measurements only; do not use it for liquid or other non-compatible gas analysis.
• Confirm your flue gas analyser has a compatible bayonet fitting before purchase.

Tradie Pro Tip

"When you're trying to get a reading from a tough spot, don't just jam it in. Take your time bending this probe – the flexibility is its strength, so use it. It'll save you from scratching up a boiler or busting a cheaper rigid probe."

Pair With

Pair this flexible probe with a Testo Flue Gas Analyser from HVAC Shop's range and ensure you have plenty of Spare Particle Filters on hand to keep your analyser running clean.
