Description
Embraco EMX6152U Medium Temp Compressor (1/4 HP, R290)
When a commercial under-bench chiller, prep fridge, or beverage display drops its temperature, premium produce and expensive stock are on the line. You need a replacement that drops in smoothly, pulls the cabinet down fast, and runs reliably during the busiest services. The Embraco EMX6152U is a highly efficient, 1/4 HP Medium Back Pressure (MBP) compressor engineered specifically to drive medium-temperature applications using the eco-friendly, high-performance R290 natural refrigerant.
Key Features & Trade Benefits
- R290 Optimized Performance: Engineered exclusively for R290 (Propane). It offers brilliant thermodynamic efficiency, drastically lowering energy consumption while boasting an ultra-low Global Warming Potential (GWP).
- Medium Temp Specialist: Designed for MBP applications, providing consistent, reliable cooling power perfect for commercial display fridges, glass-door merchandisers, and prep bench chillers.
- EMX Series Efficiency: The EMX platform is renowned for its ultra-compact size and advanced motor design, delivering incredible efficiency and whisper-quiet operation—perfect for front-of-house displays or noise-sensitive café environments.
- Trusted Embraco Reliability: Embraco sets the global standard for commercial refrigeration. Expect smooth starts, robust mechanical longevity, and stable performance even under heavy loads.
Why This Compressor Matters on the Job
Aussie hospitality environments don't do "average" conditions. When a café kitchen hits 40°C during the lunch rush, with fridge doors constantly swinging open, the compressor takes an absolute beating. The EMX6152U is built specifically for these high-stress cycles. Its superior motor cooling and efficient displacement mean it can recover safe food storage temperatures incredibly fast, protecting your client's inventory and preventing frustrating callback jobs.
Tradie Pro Tip for R290:R290 is a highly flammable (A3 safety class) hydrocarbon. Treat it with respect. Never unbraze a live system. Always recover the refrigerant safely with an A3-rated recovery machine, purge the lines thoroughly with dry oxygen-free nitrogen (OFN), and ensure your work area is heavily ventilated before striking a torch. Accurate weigh-in of the new charge is critical for MBP systems to avoid flooding the compressor.
What’s Included
- 1 × Embraco EMX6152U Medium Temp Compressor (1/4 HP, R290)
- Note: Standard starting components, relays, and covers supplied as per factory Embraco packaging.
Specifications
| Attribute | Details |
|---|---|
| Brand & Model | Embraco EMX6152U |
| Application | MBP (Medium Back Pressure) / Med Temp |
| Refrigerant | R290 (Propane) |
| Nominal Horsepower | 1/4 HP |
| Cooling Capacity (-10°C) | Approx. 520 Watts |
| Displacement | 5.19 cm³ |
| Power Supply | 220-240 V 50 Hz |
| Weight | Approx. 7.8 kg |
Frequently Asked Questions (FAQ)
What is the difference between Medium Temp (MBP) vs Low Temp (LBP), and how does Horsepower (HP) factor into R290 compressors?
Selecting the right compressor requires understanding three main factors: Application (Temp), Capacity (HP), and Refrigerant (R290). Here is how they break down:
- Medium Temp (MBP) vs. Low Temp (LBP): Medium Back Pressure (MBP) compressors like this EMX6152U are designed for standard refrigeration (chillers, prep fridges, beverage displays) operating between -10°C and +5°C. Low Back Pressure (LBP) compressors are designed specifically for deep freezing applications (freezers, ice cream cabinets) operating down to -25°C or lower. You cannot swap an LBP for an MBP.
- Low HP (e.g., 1/4 HP) vs. Med/High HP (e.g., 1/2 HP): Horsepower indicates the physical cooling capacity (muscle) of the compressor. A "low" HP compressor (1/4 HP) is perfect for smaller, single-door under-bench fridges. A "medium" to high HP compressor (like a 1/2 HP or 1 HP) has a much larger displacement and is required for massive multi-door uprights or walk-in cabinets that need to shift huge volumes of heat.
- The R290 Factor: Whether it is a 1/4 HP MBP fridge or a 1 HP LBP freezer, if it uses R290, it benefits from incredible energy efficiency and cooling performance. However, because R290 is flammable, all R290 compressors (regardless of HP or temp) utilize specialized non-sparking electrical relays and overloads to guarantee safety.
Can I use this compressor to retrofit an older R134a fridge?
No. Upgrading a system originally designed for a non-flammable refrigerant (like R134a) to a highly flammable hydrocarbon (R290) is illegal in many jurisdictions without strict engineering overhauls. R290 systems require non-sparking electrical components and specific charge limits. Always replace like-for-like.
What type of oil does the Embraco EMX6152U use?
This compressor comes factory-charged with Polyol Ester (POE) oil. POE oil absorbs moisture from the atmosphere very rapidly. Do not unseal the compressor stubs until you are completely ready to braze it into the system, and always install a fresh, appropriately sized liquid line filter drier.
