Brivis Filter Pads Set for AD/AC Series Evaporative Coolers

Keep your Brivis evaporative cooler running clean and efficient with this genuine replacement filter pad set. These pads are crucial for trapping dust and airborne particles before they can foul the heat exchange surfaces, which is especially important during a long Aussie summer.

After a few seasons, old pads get loaded up with dust and mineral scale, making your unit work harder and costing you more to run. Swapping them out is a straightforward maintenance task that pays for itself.

Best For

• HVAC service technicians
• Evaporative cooler maintenance teams
• Competent DIY homeowners performing Brivis evaporative cooler maintenance

Compatibility

This filter pad set is specifically designed for the Brivis AD and AC series evaporative coolers. It includes four pads that suit the following models:

• AD43
• AD52
• AD53
• AD54
• AD55
• AD56
• AD66
• AC60

If you're running a different model, check dimensions and specs before ordering.

Features

• OEM Fit: Precision cut to original Brivis specifications (825x530x100mm) for a perfect seal and optimal performance.
• Improved Air Quality: Efficiently traps dust, pollen, and other airborne particles, delivering cleaner, fresher air indoors.
• Optimised Performance: Ensures maximum evaporative efficiency, helping your cooler run as intended with less strain on components.
• Cost-Effective Maintenance: Regular pad replacement prevents fan motor overload and reduces energy consumption by maintaining proper airflow.
• Convenient Set: Comes as a complete set of four pads, providing everything needed for a full replacement.

Technical Specifications

What's in the Box

• 4 x Brivis Filter Pads (825mm x 530mm x 100mm each)

Using It on the Job

1. Power Down: Always isolate power to the evaporative cooler at the mains switchboard before commencing any work. Ensure it's locked out if possible.
2. Access Panels: Carefully remove the outer casing or access panels to expose the old filter pads. Note how they are seated.
3. Remove Old Pads: Unclip or slide out the existing, often dirty and calcified, filter pads. Be prepared for some mess.
4. Clean Sump: Take the opportunity to thoroughly clean out the water sump at the bottom of the unit, checking for mineral scale build-up and blockages.
5. Install New Pads: Position the new Brivis filter pads into their respective slots, ensuring they sit snugly and fully cover the openings.
6. Reassemble & Test: Replace access panels and casing securely, then restore power and test the unit for proper operation, checking water flow over the new pads.

Limitations & Safety Notes

• These filter pads are designed exclusively for Brivis AD/AC series evaporative coolers. Do not attempt to modify them for other brands or models.
• Always ensure the evaporative cooler's power is isolated and locked out before performing any maintenance to prevent accidental startup.
• Dispose of old filter pads responsibly, as they may contain accumulated dust, mineral deposits, and potentially mould.
• Regular inspection and cleaning of the water distribution system (drip trays, float valve) should be done concurrently with pad replacement to maintain system hygiene.

Tradie Pro Tip

When you're pulling out those old pads, take a moment to really scrub out the water reservoir and check the float valve. A build-up of gunk in there messes with water flow, can cause overflows, and shortens the life of your new pads. Also, give all the electrical wiring a quick once-over for any signs of corrosion or rodent damage.

Pair With

Pair with replacement evaporative cooler pumps or float valves for a full service, or check out our range of antimicrobial water treatments to keep your system cleaner for longer and reduce odours.
