Breezair ICON Control Box CPMD DD2

The Breezair ICON Control Box CPMD DD2 (SY109930) is a direct replacement part engineered to get your Breezair evaporative cooler back up and running smoothly. When your old control box dies, often due to a power surge or just plain wear and tear from harsh Australian summers, this is the essential component you need.

It's a frustrating job when an evaporative cooler's control board glitches, leaving you with no effective cooling on a scorching hot day. This replacement ensures reliable operation for your unit's fan, pump, and dump valve cycles.

Best For

• HVAC technicians and service teams working on evaporative coolers.
• Evaporative cooler maintenance specialists.
• Competent DIY homeowners maintaining their own Breezair systems.

Compatibility

This control box is designed specifically for Breezair EXH and EZH series evaporative cooler units. It's a direct fit and replacement for Seeley part number 109930. If you're running a different model, check fittings and specs before ordering.

Features

• Direct replacement for the original ICON Control Box CPMD DD2.
• Ensures proper operation of all evaporative cooler functions.
• Manufactured to match original equipment specifications.
• Essential control component for EXH and EZH series Breezair units.

What's in the Box

• 1x Breezair ICON Control Box CPMD DD2 (SY109930)

Using It on the Job

1. Always isolate power to the evaporative cooler at the main switchboard before starting any work. Apply lockout/tagout procedures as necessary.
2. Carefully disconnect all wiring from the old control box. Take photos or make a wiring diagram if you're unsure, to ensure correct re-connection.
3. Remove the old control box and mount the new Breezair ICON Control Box CPMD DD2 (SY109930) securely in its place.
4. Reconnect all wiring according to your diagram or photos, ensuring secure and correct connections to all terminals.
5. Restore power to the unit and test all functions of the evaporative cooler using the wall controller, checking fan speeds, pump operation, and dump cycles.

Limitations & Safety Notes

• Always ensure power is isolated and locked out before attempting any electrical work on evaporative cooling units.
• This control box is only for use with compatible Breezair EXH/EZH units as specified.
• Electrical work on HVAC systems should only be performed by appropriately qualified and licensed personnel.
• Always follow the manufacturer's installation instructions and relevant Australian electrical safety standards.

Tradie Pro Tip

Before replacing a control box, always double-check the wall controller and other wiring for obvious damage, corrosion, or loose connections. Sometimes the issue isn't the main board itself, which can save you a job and the cost of a new part.

Pair With

Pair with replacement filter pads and a new float valve to give your Breezair evaporative cooler a full service while you're working on it. You might also want to check out our range of universal evaporative cooler parts for other common repair items.
