Braemar CPMD Wall Controller Loom 4 Pin Low Voltage 20M

When you're running a Braemar ducted heating or cooling system, getting that wall controller exactly where it's needed can be tricky. This Braemar CPMD Wall Controller Loom, 20 metres long, gives you the reach you need to properly site your Spectrolink thermostat, ensuring a neat and professional installation, especially in larger homes or commercial spaces.

There's nothing worse than having to join low voltage wiring in a wall cavity, especially when running to a critical control point. This pre-made loom avoids that hassle, offering a reliable, plug-and-play solution.

Best For

• HVAC installers needing extra length for Braemar wall controller placement.
• Electricians working on ducted heating/cooling system wiring.
• Competent DIY owners maintaining or relocating their Braemar wall controller.
• Anyone looking to extend their Spectrolink controller with a reliable, pre-terminated loom.

Compatibility

This loom is specifically designed for Braemar ducted heating and cooling systems that use Spectrolink wall controllers. It features a 4-pin low voltage connection, ensuring it integrates seamlessly with compatible Braemar units. If you're running a different model, check fittings and specs before ordering.

Features

• Direct Fit for Braemar: Engineered as a genuine replacement or extension for Braemar Spectrolink wall controllers.
• Generous 20-Metre Length: Provides ample reach for flexible controller placement in most residential and light commercial setups.
• 4-Pin Low Voltage: Standard connection type for Braemar controllers, simplifying installation.
• Durable Construction: Built to withstand typical installation stresses and provide reliable signal transmission over its lifespan.

Technical Specifications

What's in the Box

• 1 x Braemar CPMD Wall Controller Loom, 20M (SY832777)

Using It on the Job

1. Isolate Power: Before starting any wiring work, ensure the power supply to the Braemar unit and controller is completely isolated at the main switchboard and verified de-energised.
2. Plan Your Route: Map out the most efficient and protected path for the loom from the main unit to the desired wall controller location. Avoid areas with potential interference or physical damage.
3. Connect Securely: Plug one end of the 4-pin loom into the Braemar unit's control board and the other into the back of the Spectrolink wall controller. Ensure connectors are seated firmly.
4. Route and Secure: Run the cable cleanly through walls, ceilings, or conduit. Use cable clips or ties to secure it at regular intervals, preventing sagging or accidental damage.
5. Restore & Test: Once fully connected and secured, restore power and test the wall controller's functionality to ensure all commands are registering correctly.

Limitations & Safety Notes

• This loom is for low voltage control circuits only; do NOT connect to mains electrical power.
• Ensure power to the HVAC system is fully isolated before attempting any connection or disconnection.
• Only for use with compatible Braemar Spectrolink wall controllers. Improper connection may damage the controller or system.
• Follow all relevant Australian electrical standards and Safe Work practices when installing.

Tradie Pro Tip

Always run low voltage control wiring separate from high voltage power cables to prevent electrical interference that can cause glitches in your controller's readings or operation. Secure it properly to avoid snags.

Pair With

This loom pairs well with Braemar wall controllers and other Braemar spare parts. Consider also checking out our range of cable ties and conduit for a tidy installation.
